Item#: 400
General Formulations 400 High Gloss UV Laminate Film
- UV inhibitors extend life of prints
- High gloss finish
- Exterior graphics
- Also use 401 and 402 finishes
Technical Specifications
|
Adhesion
|
- To stainless steel 48 oz/in.
- Tested according to PSTC-101 Method A procedures.
- 24 hr. dwell at 70° F and 50% relative humidity.
- Typical values. Individual values may vary. Test thoroughly before production.
|
|
Dimensional Stability
|
Good
|
|
Expected Exterior Exposure
|
Up to 4 years under normal conditions (Vertical Surfaces)
|
|
Gloss 60° Gardner
|
Initial ° 60
|
|
Light Transmission
|
Approximately 90%@ 550 nm
|
|
Storage Stability
|
1-year shelf life when stored at 70° F and 50% relative humidity.
|
|
Temperature Ranges
|
- Minimum application temperature +40° F
- Service temperature range -40° F to +180° F.
|
|
Thickness
|
- Film 3.0 mils.
- Adhesive .8 to 1.0 mil.
- Liner 4.0 mils.
- (Thickness variance +/- 10%)
|
