General Formulations 402 Matte Clear UV Laminate

Tell a Friend

Adhesion	To stainless steel 48 oz/in. When tested according to PSTC-101 Method A procedures. 24 hr. dwell at 70° F and 50% relative humidity. Typical values. Individual values may vary. Test thoroughly before production.
Dimensional Stability	Good
Expected Exterior Exposure	Up to 4 years under normal conditions (Vertical Surfaces)
Gloss 60° Gardner	Initial ≤15
Light Transmission	Approximately 85 % @ 550nms
Storage Stability	1-year shelf life when stored at 70° F and 50% relative humidity.
Temperature Ranges	Minimum application temperature +40° F Service temperature range -40° F to +180° F.
Thickness	Film 3.0 mils. Adhesive .8 to 1.0 mil. Liner 4.0 mils. (Thickness variance +/- 10%)
