Item#: 113
General Formulations 113 Clear Polyester Mounting Film
- One side permanent one side removable
- Great for window decals/graphics
- Concept® 113 is self wound on a 1.25 mil clear polyester liner
- Concept® 113 is a double-coated pressure senitive 1.0 mil clear fill with 200-4985 permant adhesive on one side and 200-4982 removable on the other side
Technical Specifications
|
Adhesion
|
- Removable Adhesive (ARLT)
- (AP adhesive laminated to 2-mil polyester film before adhesion testing)
- To glass 5 to 15 oz. / in.
- To standard test panels 5 to 15 oz. /in.
- When tested according to PSTC-101 Method A with a 24-hr. dwell at 70° F and 50%
- relative humidity. Typical values. Individual values may vary.
- Test thoroughly before production.
|
|
Dimensional Stability
|
Good
|
|
Exterior Application
|
- Removability of 200-4982 adhesive from standard window glass is up to 6 months under
- normal exposure conditions.
|
|
Storage Stability
|
One year shelf life when stored at 70° F and 50% relative humidity.
|
|
Temperature Ranges
|
- Minimum application temperature +30° F.
- Surface must be clean and dry. Keep Concept? 113 warm as possible before application.
- Service temperature range -40° F to +180° F.
|
|
Thickness
|
- Film 1.0mils.
- Adhesive 0.8 to 1.0 mils each side.
- Liner 1.2 to 1.4 mils.
- (Thickness variance +/- 10%)
|
