Item#: 103
General Formulations 103 Textured Overlaminating Film
- Textured matte finish
- Protects from abrasion, moisture and other environmental exposures
- Low-glare textured finish
- Durable heat resistant lamination
Technical Specifications
|
Adhesion
|
- To stainless steel 40 oz/in. When tested according to PSTC-101 with 24 hr. dwell at 70° F and 50% relative humidity.Typical values. Individual values may vary. Test thoroughly before production
|
|
Dimensional Stability
|
Good
|
|
Exterior Durability
|
Indoor applications only
|
|
Gloss 60 Gardner
|
Approximately 19.2
|
|
Light Transmission
|
Approximately 84% @ 550 nms
|
|
Storage Stability
|
1 year shelf life when stored at 70° F >and 50% relative humidity.
|
|
Temperature Ranges
|
- Minimum application temperature +40° F
- Service temperature range -40° F to +200° F.
|
|
Thickness
|
- Film 5.0 mils.
- Adhesive 1.4 to 1.6 mils.
- Liner 1.5 mils.
- Thickness variance +/- 10%)
|
