Item#: 270
General Formulations 270 WindowMark™ Perforated Film 70/30
- A 6.0 mil white front side and black adhesive side flexible vinyl film with a clear removable acrylic pressure sensitive adhesive on a layflat liner.
- The removable pressure sensitive adhesive is designed for excellent compatibility with vinyl films to give clean removal from glass.
- This product is designed for production of see through graphics for windows. Open area is approximately 70/30 (30% open) with a hole size of .060 inches (1.5 mm).
- Recommended for use on flat vertical commercial store windows.
Technical Specifications
Adhesion
|
- To glass 8 oz/ in
- Tested according to PSTC-101 Method A procedure with 24 -hour dwell at 70° F and 50%
- relative humidity. Typical values. Individual values may vary. Test thoroughly before
- production.
|
Dimensional Stability
|
Good
|
Expected Exterior Exposure
|
Up to two (2) years outdoor durability under normal exposure conditions.
|
Humidity Resistance
|
Excellent
|
Removability
|
Removable up to one (1) year under normal exposure conditions.
|
Solvent Resistance
|
Good
|
Storage Stability
|
One (1) year shelf life when stored at 70° F and 50% relative humidity.
|
Temperature Ranges
|
- Minimum application temperature +40° F.
- Service temperature 0° F to +150° F.
|
Thickness
|
- Film 6.0 mils.
- Adhesive .8 to 1.0 mil.
- Liner 6.0 mils.
- (Thickness variance +10%)
|
Water Resistance
|
Excellent
|
