Item#:  270

General Formulations 270 WindowMark™ Perforated Film 70/30

  • A 6.0 mil white front side and black adhesive side flexible vinyl film with a clear removable acrylic pressure sensitive adhesive on a layflat liner.
  • The removable pressure sensitive adhesive is designed for excellent compatibility with vinyl films to give clean removal from glass.
  • This product is designed for production of see through graphics for windows. Open area is approximately 70/30 (30% open) with a hole size of .060 inches (1.5 mm).
  • Recommended for use on flat vertical commercial store windows.

Technical Specifications

Adhesion
  • To glass 8 oz/ in
  • Tested according to PSTC-101 Method A procedure with 24 -hour dwell at 70° F and 50%
  • relative humidity. Typical values. Individual values may vary. Test thoroughly before
  • production.
Dimensional Stability Good
Expected Exterior Exposure Up to two (2) years outdoor durability under normal exposure conditions.
Humidity Resistance Excellent
Removability Removable up to one (1) year under normal exposure conditions.
Solvent Resistance Good
Storage Stability

One (1) year shelf life when stored at 70° F and 50% relative humidity.

Temperature Ranges
  • Minimum application temperature +40° F.
  • Service temperature 0° F to +150° F.
Thickness
  • Film 6.0 mils.
  • Adhesive .8 to 1.0 mil.
  • Liner 6.0 mils.
  • (Thickness variance +10%)
Water Resistance Excellent

Resources

Name
Resources 270.pdf

General Formulations 270 WindowMark™ Perforated Film 70/30 - 54" X 100'
Availability: In stock
Sku: 270-54
Price: $588.63 ( 1.25 /SQ. FT.)
General Formulations 270 WindowMark™ Perforated Film 70/30 - 60" X 100'
Availability: In stock
Sku: 270-60
Price: $653.09 ( 1.25 /SQ. FT.)
