Item#:  209

General Formulations 209 MetroMark™ Transit Vinyl

  • Temporary vehicle decals
  • Billboard display
  • Pop and decals
  • Removable adhesive

Technical Specifications

  • To stainless steel 8 oz/in.
  • PSTC-1 with 24 hour dwell at 70° F and 50 % relative humidity.
  • Typical values. Individual values may vary. Test thoroughly before production.
Expected Exterior Exposure

Removable for up to one year from most smooth original equipment finishes with little or no residue remaining on the finish.

Humidity Resistance Excellent

Up to 6 months from most common commercial tile floors. Floor must be clean before application. All tiles must be firmly attached to the sub floor. Painted floors must have excellent adhesion to the sub floor. Test all painted cement floors for adhesion of the paint before applying a floor decal.

Shelf Stability

6-month shelf life when stored at 70° F and 50% relative humidity.

Solvent Resistance Excellent
Substrate Protection

Metromark will not damage the painted surface on stable OEM or repainted motor coach surfaces. Note: Stable paint surface is defined as a positive paint bond between paint and paint receptive surface of at least 320 ounces per inch peel adhesion.

Substrate Recommendation

Metromark films are designed for use on smooth, flat substrates. The product should not be applied over rivets or corrugated surfaces. Gaps between two panels must be sealed before applying Metromark™ Vinyl. Up to three layers may be applied provided the original Metromark signage has been applied six months or less. If layering, must test adhesion of top decal to the printed surface. Some inks and clear over- prints contain slip agents that may reduce adhesion.

Temperature Ranges
  • Minimum application temperature +40° F.
  • Service Temperature -40° F to +180° F.
  • Film 3.4 mils.
  • Adhesive 0.8 to 1.0 mils.
  • Liner 6.7 mils.
  • (Thickness variance +/- 10%)
Water Resistance Good. Do not saturate


Resources 209.pdf

General Formulations 209 MetroMark™ Transit Vinyl - 54" X 150'
Availability: In stock
Sku: 209-54
Price: $236.79 ( 0.34 /SQ. FT.)
General Formulations 209 MetroMark™ Transit Vinyl - 64" X 150'
Availability: In stock
Sku: 209-64
Price: $278.55 ( 0.34 /SQ. FT.)
