Item#: 242
General Formulations 242 Optically Clear Cast Overlaminating Film
- Optically clear lamination
- Cast vinyl for stability
- Great for perforated vinyl
- Extend life of print
Technical Specifications
|
Adhesion
|
- To stainless steel 48 oz/in.
- When tested according to PSTC-101 Method A with 24 hr. dwell at 70° F and
- 50% relative humidity. Typical values. Individual values may vary.
- Test thoroughly before production.
|
|
Dimensional Stability
|
Good
|
|
Expected Exterior Exposure
|
Under normal conditions, up to 5 years resistance can be expected.
|
|
Storage Stability
|
1-year shelf life when stored at 70°XF and 50% relative humidity.
|
|
Surface Gloss
|
- >60
- Gloss Meter 60° viewing angle
|
|
Temperature Ranges
|
- Minimum application temperature +40° F
- Service temperature range -40° F to +180° F.
|
|
Thickness
|
- Film 2.0 mils.
- Adhesive . 9 to 1.1 mils.
- Liner 4.0 mils.
- (Thickness variance +/- 10%)
|
