General Formulations 213 Traffic Graphic™ UL Floor Laminate

Tell a Friend

Adhesion	To stainless steel 40 Oz. / In. Tested according to PSTC-101 Method A with 24-hour dwell at 70°XF and 50% relative humidity. Typical values. Individual values may vary. Test thoroughly before production.
Durability	GF 213 will function as a floor overlaminate for six (6) months under normal use.
Expected Exterior Exposure	This product is designed for interior applications.
Humidity Resistance	Excellent
Indirect Food Contact	The film and adhesive complies with the following citations in 21CFR 174 thru 182and 21CFR 175.105 respectively
Slip Resistance	GF 213 is classified under UL 410 for floor graphics overlay applications.
Storage Stability	Six (6) months shelf life when stored at 70° F and 50% relative humidity.
Temperature Ranges	Minimum application temperature +40° F. Service temperature -40° F to +200° F.
Thickness	Film 3.75 mils. Adhesive .8 to 1.1 mils. Liner 4 mils. (Thickness variation +/- 10%)
Water Resistance	Good
