Item#:  401

General Formulations 401 Luster UV Clear Laminate

  • UV inhibitors extend life of prints
  • Luster finish
  • Exterior graphics
  • Also use 400 and 402 finishes

Technical Specifications

Adhesion
  • To stainless steel 48 oz/in.
  • Tested according to PSTC-101 Method A procedures.
  • 24 hr. dwell at 70° F and 50% relative humidity.
  • Typical values. Individual values may vary. Test thoroughly before production.
Dimensional Stability Good
Expected Exterior Exposure Up to 4 years under normal conditions (Vertical Surfaces)
Gloss 60° Gardner Initial 30-50
Light Transmission Approximately 87%
Storage Stability

1-year shelf life when stored at 70° F and 50% relative humidity.

Temperature Ranges
  • Minimum application temperature +407deg; F
  • Service temperature range -40° F to +180° F.
Thickness
  • Film 3.0 mils.
  • Adhesive .8 to 1.0 mil.
  • Liner 4.0 mils.
  • (Thickness variance +/- 10%)

Resources

Name
Resources 401.pdf

General Formulations 401 Luster UV Clear Laminate - 54" X 150'
Availability: In stock
Sku: 401-54
Price: $226.35 ( 0.32 /SQ. FT.)
General Formulations 401 Luster UV Clear Laminate - 60" X 150'
Availability: In stock
Sku: 401-60
Price: $250.56 ( 0.32 /SQ. FT.)
