Item#: 100
General Formulations 100 High Gloss Overlaminating Film
- High gloss photography finish
- Protects from abrasion, moisture and other environmental exposures
- Maximize print life
Technical Specifications
|
Adhesion
|
- To stainless steel 48 oz/in.
- When tested according to PSTC-101 Method A procedures.
- 24 hr. dwell at 70° F and 50% relative humidity.
- Typical values. Individual values may vary. Test thoroughly before production.
|
|
Dimensional Stability
|
Good
|
|
Expected Exterior Exposure
|
- This product is designed for interior applications.
- Exterior resistance has not been determined.
|
|
Gloss 60 Gardner
|
Initial > 80
|
|
Light Transmission
|
Approximately 90% @ 550 nm
|
|
Storage Stability
|
1-year shelf life when stored at 70° F and 50% relative humidity.
|
|
Temperature Ranges
|
- Minimum application temperature +40° F
- Service temperature range -40° F to +180° F
|
|
Thickness
|
- Film 3.0 mils.
- Adhesive .8 to 1.0 mil.
- Liner 4.0 mils.
- (Thickness variance +/- 10%)
|
